120W 110-220V AC Gear Motor Small Induction Motor
2 Customer Reviews
This 120W 110-220V AC Gear Motor is a small and powerful induction motor. It offers reliable performance while delivering on energy efficiency. Its design allows for a wide range of motion control applications, making it ideal for industrial use.
| Model | Voltage | Frequency | Current | Starting Rated Capacitor | |||
| Torque | Torque | Speed | |||||
| Lead Wire | Terminal Box | V | Hz | A | mN.m | mN.m | R/min |
| 6IK120GU-AF | 6IK120GU-AFT | 1ph 100 | 50 | 2.1 | 600 | 930 | 1250 |
| (6IK120A-AF) | (6IK120A-AFT) | 1ph 100 | 60 | 2.5 | 600 | 750 | 1550 |
| 6IK120GU-EF | 6IK120GU-EFT | 1ph 110 | 60 | 1.7 | 600 | 750 | 1550 |
| (6IK120A-EF) | (6IK120A-EFT) | 1ph 120 | 60 | 1.8 | 600 | 750 | 1550 |
| 6IK120GU-CF | 6IK120GU-CFT | 1ph 220 | 50 | 0.95 | 750 | 930 | 1250 |
| (6IK120A-CF) | (6IK120A-CFT) | 1ph 230 | 50 | 0.95 | 750 | 930 | 1250 |
| 6IK120GU-HF | 6IK120GU-HFT | 1ph 220 | 60 | 0.95 | 700 | 750 | 1550 |
| (6IK120A-HF) | (6IK120A-HFT) | 1ph 230 | 60 | 1 | 700 | 750 | 1550 |
| 6IK120GU-SF | 6IK120GU-SFT | 3ph 220 | 50 | 0.75 | 2200 | 890 | 1300 |
| (6IK120A-SF) | (6IK120A-SFT) | 3ph 220 | 60 | 0.7 | 2000 | 730 | 1600 |
